FEATURES

1.The frames on both sides are welded from high-quality steel, and the structure is stable.

2.The conveying curtain adopts tight wooden curtain, which is fed by groove rollers.

3.The opening roller is made of high-quality seamless steel pipe after finishing and balance, and is spirally implanted into the horn teeth.

4.The cotton storage box is equipped with a strong magnet and metal removal device. The cotton conveying fan is connected to the PVC cotton conveying pipe.

5.The feeding curtain operation is controlled by the photoelectric switch of the cotton box, which automatically controls the feeding amount.

6.Safety protection:

(1) All transmission parts are protected by protective covers.

(2) The electrical part is provided with overload protection, overcurrent protection, short circuit protection and emergency stop button.

(3) Warning signs are required for necessary parts.



SPECIFICATION:

Model

CYLKS-1300

CYLKS-1500

CYLKS-1600

CYLKS-1900

CYLKS-2200

Working width

1300mm

1500mm

1600mm

1900mm

2200mm

Capacity

≤250kg/h

≤300kg/h

≤350kg/h

≤500kg/h

≤600kg/h

Opening roller diameter

D=400mm

D=500mm

D=500mm

D=600mm

D=600mm

Power

11kw

13kw

13kw

20kw

20.kw

Feeding roller diameter

D=86mm

Opening roller type

Claw nail type/card clothing type acoording custom need
